| Mercury Model
No. |
L-12 |
L-25 |
L-30 |
L-35 |
L-40 |
L-60 |
L-75 |
L-100 |
L-120 |
| Laser Source |
12W |
25W |
30W |
35W |
40W |
60W |
75W |
100W |
120W |
|
Air Cooled, Sealed CO2 laser |
| Work Area |
25" x 18" ( 635mm x 457mm ) |
Max. Working Piece
(all doors closed) |
31.5" x 22.4" ( W: 800mm x D: 570mm x Thick : 165mm ) |
Max. Working Piece
(all doors
open) |
26.8" x unlimited x 6.5" ( W : 680mm x D :
unlimited x Thick : 165mm ) |
| Table Size |
31" x 20.9" ( 790mm x 530mm ) |
| Overall Dimensions |
44.3" x 28.3" x 39.6" ( 1125mm x 720mm x 1005mm
) |
| Drive |
DC servo control |
| Speed Control |
Adjustable from 0.1% to 100% of 42 inch/sec with
up to 16 colors linked speed setting per job |
| Power Control |
Adjustable from 0.1% ~ 100% and 16 colors linked power setting per
job |
| Z Axis Moving |
Automatic |
| Resolution (DPI) |
200, 250, 300, 500, 600, 1000 |
| Computer Interface |
Print port and serial port for PC |
| Memory Buffer |
16MB standard and upgradable to 64 MB with SIMM modules. Multiple
file mode saves up to 100 files. |
| Display Panel |
4-line LCD display showing current file name,
total working time. Laser power, engraving speed, file loaded into memory
buffer, setup and diagnostic menus. |
| Power |
100 ~ 240V, AC Auto Switch |
200 ~ 240V |
| Power Consumption |
900W |
1100W |
2000W |
3000W |
