ÀÛ¾÷¸éÀû(Working Area) |
950 * 650mm |
Å×À̺í¸éÀû(Table Area) |
950 * 650mm
|
ÀÛ¾÷³ôÀÌ(Z Axis Stroke) |
150mm |
Á¶°¢¼Óµµ(Cutting Speed) |
0.2~240mm/sec |
ÇØ»óµµ(Resolution) |
0.01mm |
Á¦¾îÀåÄ¡¿¬°á(Interface) |
LAN |
µ¿ ·Â(Power Supply) |
220V/60Hz ´Ü»ó |
½ºÇɵé¸ðÅÍ(Spindle Motor) |
DC 1Kw Heatronic Motor |
½ºÇɵéȸÀü¼ö(Spindle RPM) |
20,000 RPM |
Ư¡(Features)
¢º¸ðµçÃà¿¡ ¿¬»èº¼ ½ºÅ©·ù »ç¿ë Precision Ballscrews on all axis ¢º¸ðµçÃà¿¡
L/M»ç¿ë Precision Linear Motion Bearing on all
axis ¢º°·ÂÇÑ AC¼º¸¸ðÅÍ »ç¿ë High Power AC
Servo Motors on all axis ¢ºZÃà ³ôÀÌ 150mm·Î È°¿ë¼º ¹è°¡ Z axis Stroke 150mm make a usefull work ¢º1 Kw DC
¿µ±¸ÀÚ¼® ¸ðÅÍ¿Í ½ºÇɵéÀ» ÀÚü °³¹ßÇÔÀ¸·Î¼ °·ÂÇÑ Àý»è·Â ¹ßÈÖ Our
1Kw DC Brushless Motor and Spindle is high Frequency cutting power
¢ºÄÜÆ®·Ñ ½Ã½ºÅÛÀ» HPGL Mode¸¦ »ç¿ëÇÔÀ¸·Î µ¥ÀÌÅÍ È£È¯¼ºÀÌ ¶Ù¾î³²
Control System's very good at of compatible data
by using HPGL mode ¢º±¹³»Á¦ÀÛÀ¸·Î A/S°¡ ¿øÈ°ÇÏ´Ù It is very convenient to get after Service
»ç¿ëºÐ¾ß(Application)
¢º2Â÷¿ø ¹× 3Â÷¿ø Á¶°¢(3D ´Â »çÀοë 3DÀÔ´Ï´Ù) Engraving of 2D, 3D ¢º3Â÷¿ø ¸ôµùÀÛ¾÷ 3D Mold Processing ¢ºPCB ±âÆÇ°¡°ø PCB routing and drilling ¢ºµå¸±ÀÛ¾÷ Drilling
°¡°ø¼ÒÀç(Processing Materials)
¢ºÇöó½ºÆ½·ù(Plastics)
¾ÆÅ©¸±(Acrylic), PVC, Çø®Ä«º¸³×ÀÌÆ®(Polycarbonate) Æ÷¸ß½º(Foam),
¶ó¹Ì³×ÀÌÆ®(Laminates), ÀÎÁ¶´ë¸®¼®(Marble) ¢ººñö±Ý¼Ó·ù(Metals) ¾Ë·ç¹Ì´½(Aluminium), Ȳµ¿(Brass), ±¸¸®(Copper) ¾Æ¿¬(Zinc),
ûµ¿(Bronze) ¢º¸ñÁ¦·ù(Wood) °¸ñ(Hardwood), ¿¬¸ñ(Softwood), ÇÕÆÇ(Plywood)
|
